| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
USA
25-512 / 758-824 / 849-869 / 894-960 / 1240-1300 MHz
|
| Tuning steps: | 5 / 6.25 / 7.5 / 8.33 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 KHz |
| Frequency stability: | ? ppm |
| Mode: |
Analog:
AM / FM / NFM / FMB / WFM
DV modes:
| APCO P25 I/II | C4FM | IMBE |
|
| DMR/MotoTRBO | C4FM | AMBE+2 | (Paid upgrade required) |
| EDACS ProVoice | C4FM | IMBE | (Paid upgrade required) |
| NXDN | C4FM | AMBE+2 | (Paid upgrade required) |
|
| Channels / memory management: |
Enhanced dynamic memory system
7 NOAA weather channels
10 custom search ranges
Priority functions
Alpha tags
|
| Power supply: | 3.7 VDC (Li-Ion battery)
or 5 VDC external (USB-C jack) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohms / SMA |
| Dimensions (W*H*D): | 65*167*50 mm (2.56*6.58*1.97") |
| Weight: | 337 g (11.9 oz), with battery and antenna |
| Other features: |
Customizable color display. Close call. Bluetooth LE. US & Canadian
HomePatrol database. CTCSS/PL and DCS. Backlit keypad. USB-C connector.
S.A.M.E. weather alert. Recording/playback (Up to 240 seconds).
Trunktracker X. Tracks Motorola, EDACS, X2-TDMA, P25 and LTR.
IPX4/JIS4 water and dust resistant. PC programming and control. GPS.
Micro-SD card slot. Multicolor LED alert. Attenuator. Dimmer.
Waterfall display and more.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: | SDR technology with true I/Q reception |
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / 8 ohm |
| External speaker connector: | TRS "Minijack" (3.5 mm), 32-64 ohm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Vietnam, 2025-202x |
| Additional info: |
New price, december 2025 in the US: $949.99
|
| Related documents: |
User manual (2.4 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options/Accessories: |
|
