| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: | 29-54 / 108-174 / 406-512 MHz |
| Tuning steps: | ? / ? KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM |
| Channels / memory management: |
933 pre-programmed non-erasable public service channels
20 "Police" user programmable channels
10 "Fire/EMG" user programmable channels
20 "Private" user programmable channels
|
| Power supply: | 12 VDC (Barrel connector) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 132*41*174 mm (5.2*1.61*6.85") |
| Weight: | 766 g (1.69 lbs) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: |
29-54 MHz: 0.5 uV (12 dB SINAD)
108-137 MHz: 1.2 uV (no reference)
137-174 MHz: 0.7 uV (12 dB SINAD)
406-512 MHz: 0.7 uV (12 dB SINAD)
|
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 3 W at ?% distortion / ? ohm |
| External speaker connector: | 3.5 mm, 8 ohm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Philippines, 1992-199x (Discontinued)
China, 199x-200x (Discontinued) |
| Additional info: | FCC ID: AMWUB225 (Philippines)
FCC ID: AMWUB297 (China) |
| Related documents: | User manual (389 KB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
BC-AT
PLG-134
|
Multiband mobile antenna
Antenna adapter. Motorola jack-to-BNC plug
|
|
