| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
68-83 / 144-174 / 420-512 MHz (Europe)
|
| Tuning steps: | ? KHz |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
50 regular in 5 banks
|
| Power supply: | Mains or 12 VDC |
| Current drain / power consumption: | Less than 650 mA @ 13.8 VDC |
| Antenna impedance / connector: | 50-70 ohm / DIN41585 (Motorola) or telescopic whip |
| Dimensions (W*H*D): | 273*89*203 mm (10.75*3.5*8") |
| Weight: | 2.3 Kg (5 lb) |
| Other features: | Clock. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.85 MHz
2nd IF: 450 KHz
|
| Sensitivity: |
VHF: 0.4 uV
UHF: 0.8 uV
|
| Selectivity: | 25 KHz (-60 dB) |
| Image rejection: | |
| AF output power / speaker: | 2 W at 10% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1978-198x (Discontinued) |
| Additional info: | FB = Foreign Band |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
