| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
0.1-3000 MHz
(Cellular blocked in the USA)
|
| Tuning steps: |
10 / 50 / 100 / 500 Hz
1 / 2 / 5 / 6.25 / 7.5 / 8.33 / 9 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 / 500 KHz
|
| Frequency stability: | Less than ±1 ppm @ 0 to 50°C (32 to 122°F), after 5 minutes warmup |
| Mode: |
Analog:
AM / AM-synchro / FM / NFM / WFM / SSB / CW
DV modes:
| Alinco | GMSK | AMBE |
| Apco P25 | C4FM | IMBE |
| D-Star | GMSK | AMBE |
| DCR/NXDN | C4FM | AMBE+2 |
| DMR/MotoTRBO | C4FM | AMBE+2 |
| dPMR | C4FM | AMBE+2 |
| Yaesu | C4FM | AMBE+2 |
| TETRA | DQPSK | DMO (T-DM) and TMO (T-TC) |
|
| Channels / memory management: |
2000 regular in 40 banks with alpha tags
400 search pairs
50 pass per bank
Non-volatile EEPROM storage
|
| Power supply: |
10.7-16 VDC (Male barrel jack, center positive)
or 15 VDC from USB-PD.
|
| Current drain / power consumption: | Max 1 A |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 178*50*180 mm (7*1.97*7.09") |
| Weight: | 1.5 Kg (3.31 lb) |
| Other features: |
CTCSS/PL and DCS with tone search. DSP functions. Clock/timer/alarm. Audio recording.
Discriminator output. SD/SDHC card slot. USB type C jack. Digital mode autodetect.
Audio equalizer. Cyber search up to 600 steps per second. 8 different backlite
colors selectable. 14 dB switchable preamp (Above 18 MHz). Attenuator (20 dB).
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Direct sampling SDR (0.1-18 MHz)
Double conversion superheterodyne (18-3000 MHz)
1st IF: ? MHz
2nd IF: ? MHz
|
| Sensitivity: |
AM (10 dB S/N)
Less than 1 uV
FM (12 dB SINAD)
0.1-18 MHz: 0.5 uV
18-1500 MHz: 0.3 uV
1500-3000 MHz: 0.5 uV
WFM (12 dB SINAD)
60-108 MHz: 1 uV
SSB (10 dB S/N)
Less than 0.3 uV
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: |
IF bandwidths:
200 / 500 Hz
1.8 / 2.6 / 3.8 / 5.6 / 6 / 8 / 15 / 30 / 100 / 200 KHz
|
| Image rejection: | |
| AF output power / speaker: | 1 W at ?% distortion / 8 ohm |
| External speaker connector: | TS "minijack" (3.5 mm), 4-8 ohm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 2025-202x |
| Additional info: |
Updates and improvements over AR-DV1 include:
Extended frequency range.
Improved RF frontend.
Improved IF stage.
Optimized audio circuits and speaker.
Audio equalizer added.
Preliminary launch price 2025 in Japan: 217800 Yen including VAT
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
?
?
?
|
TETRA GSSI option
I/Q output unit
10.7 MHz IF output unit
|
|
