AOR AR-3030

A picture of AOR AR-3030

SPECIFICATIONS

GENERAL
Type:HF receiver
Frequency range:0.03-30 MHz (VHF option)
Tuning steps:5 / 10 / 100 Hz, 1 KHz, 1 MHz
Frequency stability:5 ppm @ -10 to +50°C (14 to 122°F)
Mode:AM / AM-sync / FM / SSB / CW / Fax
Channels / memory management: 100 regular
Power supply:12 VDC (Eight LR6 / AA batteries)
or 13.8 VDC external (3-pin connector)
Current drain / power consumption:800 mA (Nominal) @ 13.8 VDC
Antenna impedance/connector:50 ohm / BNC
450 ohm / Wire terminals
Hi-Z whip / BNC
50 ohm / BNC (For optonal VHF converter)
Dimensions (W*H*D):250*88*240 mm (9.84*3.46*9.45")
Weight:2.2 Kg (4.85 lb), without batteries
Other features:RS-232C.




RECEIVER SECTION
Receiver system: ? conversion superheterodyne
Sensitivity: AM (10 dB S+N/N)
0.03-0.05 MHz: 3 uV
0.54-1.8 MHz: 15 uV
1.8-30 MHz: 1.5 uV (Narrow)
FM (12 dB SINAD)
1.8-30 MHz: 0.5 uV
SSB/CW/FAX (10 dB S/N)
0.03-0.05 MHz: 1 uV
0.54-1.8 MHz: 5 uV
1.8-30 MHz: 0.5 uV
Selectivity: AM: 6 KHz (-3 dB)
AM Narrow: 2.4 KHz (-6 dB)
FM: 15 KHz (-6 dB)
SSB/Fax: 2.4 KHz (-6 dB)
CW: 500 Hz (-3 dB), with optional filter
Image rejection:
AF output power / speaker:1.8 W at 10% distortion / 8 ohm
External speaker connector:3.5 mm




MISCELLANEOUS
Manufactured:Japan, 1993-199x (Discontinued)
Additional info:
Related documents: User manual (334 KB)
Service manual (5.7 MB)
Modifications and fixes:
Reviews:
Options / Accessories:
?
?
DC-3000
526-8635-010
526-8634-010
Internal VHF converter, 108-140 MHz
Internal VHF converter, 140-170 MHz
DC cable
Collins SSB filter. 2.5 KHz
Collins CW filter. 500 Hz
A rear picture of AOR AR-3030
