| GENERAL |
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: |
TX: 136-174 / 400-480 MHz
RX: 87.5-108 / 108-174 / 400-480 MHz
|
| Tuning steps: | 5 / 6.25 / 8.33 KHz |
| Frequency stability: | ±2.5 ppm @ -20 to +55°C (-4 to +131°F) |
| Mode: |
TX: FM / NFM / DMR (Tier I & II) / NXDN
RX: AM / FM / NFM / WFM / DMR (Tier I & II) / NXDN
NB! NXDN may require a firmware update or unlock
|
| Channels / memory management: |
4000 regular with alpha tags
250 zones
10000 talk groups
500000 digital contacts
|
| Repeater shift / offset: | Programmable |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohms / SMA |
| Dimensions (W*H*D): | 61*129*42 mm (2.4*5.08*1.65") |
| Weight: | 293 g (10.33 oz), with battery pack |
| Other features: |
CTCSS/PL and DCS. 2 & 5-tone. DTMF. 1.77" color TFT display.
Analog APRS (TX/RX) and DMR APRS (TX/RX). Roaming. Bluetooth.
Auto-sense annalog or digital reception. GPS. Scrambler.
USB-C charging. Digital voice recorder. Crossband repeater.
SMS. VFO. Twin RX.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: |
FM: 0.25 uV (12 dB SINAD)
NFM: 0.35 uV (12 dB SINAD)
DMR: 0.3 uV (BER 5%)
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | FM: 65 dB (Adjacent channel)
NFM: 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 1 W at 5% distortion / 16 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low 1 | Low 2 |
|---|
| 2 m: | 7 W | 5 W | 2.5 W | 200 mW |
| 70 cm: | 6 W | 5 W | 2.5 W | 200 mW |
|
| Modulation system: | DMR: 4FSK |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -36 dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (By Qixiang Electron), 2025-202x |
| Additional info: |
FCC ID: T4K-D890UV
Intro price, december 2025 in Sweden: SEK 2795:- (With BT PTT)
|
| Related documents: |
User manual (1.1 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
BC-05
BP-03
CPL-01
CPL-02
EJX-023
PC-04
PT-878
QA-11UV
QB-44L
QB-44HL
QBC-47L
QHM-024
TX-0313
|
Belt clip
Bluetooth wireless PTT
Car charger
Battery eliminator
Earphone
USB programming cable
Leather case
Flexible antenna
Li-Ion battery pack. 7.4 V, 2100 mAh
Li-Ion battery pack. 7.4 V, 3100 mAh
Desk charger
Speaker-microphone
Long antenna. 38 cm (14.97")
|
|
