| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
TX: 66-88 MHz
RX: 66-88 MHz
|
| Tuning steps: | 2.5 / 5 / 6.25 / 10 / 12.5 / 20 / 25 / 30 / 50 KHz |
| Frequency stability: | ±2.5 ppm @ -20 to +60°C (-4 to +140°F) |
| Mode: | FM / NFM |
| Channels / memory management: |
199 regular with alpha tags
|
| Repeater shift / offset: | Freely programmable |
| Power supply: | 13.8 VDC ±15% |
| Current drain / power consumption: | RX: 400 mA
TX: Less than 5 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 104*25*109 mm (4.1*0.98*4.29") |
| Weight: | ? g (? oz) |
| Other features: | CTCSS/PL and DCS. PC programmable. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SoC? |
| Sensitivity: |
FM: 0.25 uV (12 dB SINAD)
NFM: 0.35 uV (12 dB SINAD)
|
| Selectivity: | >60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 2 W at ?% distortion / 16 ohm |
| External speaker connector: | 3.5 mm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low |
|---|
| 4 m: | 15 W | 10 W | 5 W |
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | 2 Kohm / Fixed cord |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (By Qixiang Electron), 20xx-20xx |
| Additional info: | New price, january 2023 in Sweden: SEK 1495:- |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
