| GENERAL |
| System: | NMT450 (Sweden and other Nordic countries) |
| Frequency range: | RX: 463.000-467.500 MHz
TX: 453.000-457.500 MHz |
| Frequency stability: | ? ppm |
| Power supply: | ? VDC (NiMH battery pack) |
| Current drain / battery life: | Standby: ? mA / 110 hrs (With standard battery pack)
Talk: ? mA / 3 hrs (With standard battery pack) |
| Impedance / antenna: | Integrated antenna
50 ohm / ?-jack |
| Dimensions (W*H*D): | 64*186*30 mm (2.52*7.32*1.18"), with standard battery pack |
| Weight: | 390 g (13.76 oz), with standard battery pack |
| Other: |
Backlit graphic display. 5*25 or 4*16 characters. Unbreakable antenna.
RS-232C. Modem. Terminal function. Time manager. Calculator.
Alarm clock. Password protection. Handsfree. Emergency/SOS button.
Text messaging between similar Spectronic units. GPS and many other
advanced options.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / impedance: | ? mW at ?% distortion / ? ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
1.5 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Handset impedance / connector: | - |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Sweden, 1992-200x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Options / Accessories: |
TS400-B1200
TS400-B2100
TS220 L220
TS220 L12
TS220 BC
TS220 D0
TS220 H0/III
TS220 LS12
TS260 J0
TS 280
TS260 RS-232
|
Standard NiMH battery pack. 1200 mAh
High capacity NiMH battery pack. 2100 mAh
Universal charger. 220-230 VAC
Car charger. 12 VDC
Belt clip
Desk stand with charging jack
Handsfree unit
Mobile mounting bracket with charger (12 VDC)
Line interface, for landline accessories
DMS modem
RS-232C cable
|
|
