| GENERAL |
| System: | AMPS 800 (USA and other countries) |
| Frequency range: | RX: 869.000-894.000 MHz
TX: 824.000-849.000 MHz |
| Frequency stability: | ? ppm |
| Power supply: | ? VDC |
| Current drain / battery life: | Standby: ? mA / ? hrs
Talk: ? mA / ? min |
| Impedance / antenna: | Removable antenna
50 ohm / ?-jack |
| Dimensions (W*H*D): | 47*165*35 mm (1.85*6.5*1.38"), with battery |
| Weight: | 232 g (8.18 oz) |
| Other: | Built on the "Jane" platform. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / impedance: | ? mW at ?% distortion / ? ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
? mW
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±6 KHz |
| Spurious emissions: | Better than -? dB |
| Handset impedance / connector: | - |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1995-199x (Discontinued) |
| Additional info: | |
| Related documents: |
PLL: NJ88C50MA
FM-IF: SA606DK
|
| Modifications and fixes: | |
| Options / Accessories: |
|
