| GENERAL |
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: |
TX: 136-174 / 400-480 MHz
RX: RX: 108-180 / 220-260 / 350-523 MHz
|
| Tuning steps: | 2.5 / 5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 KHz |
| Frequency stability: | ±2.5 ppm (No temperature reference) |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM |
| Channels / memory management: |
758 regular with alpha tags
1 call
|
| Repeater shift / offset: | ±0 to 99.995 MHz |
| Power supply: | 13.8 VDC ±15% |
| Current drain / power consumption: | RX: 300 mA
TX: Max 8 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 139*40*212 mm (5.5*1.6*8.34") |
| Weight: | 1.15 Kg (2.53 lb) |
| Other features: |
Detachable control head. CTCSS/PL and DCS. 2-tone and 5-tone selcall.
Multi color backlite. Theft alarm. Twin RX (V/U, V/V, U/U).
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: |
FM: 0.25 uV (12 dB SINAD)
NFM: 0.35 uV (12 dB SINAD)
|
| Selectivity: | FM: 70 dB (Adjacent channel)
NFM: 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 2 W at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Mid 2 | Low |
|---|
| 2 m: | 50 W | 25 W | 10 W | 5 W |
| 70 cm: | 40 W | 25 W | 10 W | 5 W |
|
| Modulation system: | Variable reactance |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | ? ohm / 8-pin (Metal locking ring connector) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2014-20xx |
| Additional info: |
The supplied microphone is actually a speaker-mike, which can be
very handy in a noisy vehicle.
New price 2015 in Germany: 298.00 Euro
New price 2015 in England: £249.95
|
| Related documents: | User manual (1.8 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
EDS-28
ERW-12
|
Separation kit
USB programming cable and software kit
|
|
