| GENERAL |
| Type: | Airband transceiver |
| Frequency range: |
TX: 118.000-135.975 MHz
RX: 118.000-135.975 MHz
|
| Tuning steps: | 25 KHz |
| Frequency stability: | 0.003% (No temperature reference) |
| Mode: | AM |
| Channels / memory management: |
No
|
| Power supply: | 13.75 VDC |
| Current drain / power consumption: | RX: 800 mA
TX: 3.5 A |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 160*45*300 mm (6.3*1.77*11.8") |
| Weight: | 1.59 Kg (3.5 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | 1.5 uV (6 dB S+N/N) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | 16 KHz (-6 dB)
50 KHz (-60 dB) |
| Image rejection: | 70 dB |
| AF output power / speaker: |
Speaker
10 W at ?% distortion / 4 ohm (No internal speaker)
Headset
50 mW at ?% distortion / 300 ohm
|
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Max 10 W
|
| Modulation system: | |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | 0.1-3 V (0.2 V factory set) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1978-198x (Discontinued) |
| Additional info: | |
| Related documents: | User manual (979 KB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
MP10
|
Voltage converter. 28 to 14 VDC
|
|
