| GENERAL |
| Type: | External DSP filter |
| Power supply: | 12 VDC (Male barrel jack, center positive) |
| Current drain/power consumption: | Max 400 mA |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? oz) |
|
|
|
|
| AUDIO SECTION |
| Noise reduction: | QRN reducer |
| Selectable bandwidths: | See the manual |
| Frequency response: | See the manual |
| Audio input: | RCA/Phono jack |
| Audio output: | RCA/Phono jack
Headphones: TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1995-xxxx (Discontinued) |
| Additional info: |
Automatic notch filter.
Improvements over the DSP II include:
13 bit audio codec instead of 8 bits for a much wider dynamic range.
Optional AGC in the LMS adaptive modes.
Software AGC in the LMS adaptive modes.
SSTV filter.
European low tones RTTY/FSK filter.
DTMF decoder with memory.
CTCSS/PL decoder with memory.
1.8 kHz brick wall SSB filter.
2.1 kHz brick wall SSB filter.
More CW filters.
CW filters can be tuned.
|
| Related documents: |
User/assembly manual (238 KB)
|
| Modifications and fixes: | |
| Reviews: |
Communications Quarterly: Summer 1995, page 85
QST: August 1995, page 73
|
| Applicable radios: | |
