| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 24 (1-23 + 11A) |
| Mode: | AM / FM |
| Frequency control: | PLL |
| Frequency stability: | 0.002% (No temperature reference) |
| Clarifier or Delta tune: | ±1 KHz |
| Power supply: | 11.6-15.6 VDC (Fixed power cord) |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 195*62*203 mm (7.68*2.44*7.99") |
| Weight: | 1.85 Kg (4.08 lb) |
| Other features: | PA. ANL/NB. Selcall jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.695 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM: 0.4 uV (10 dB S+N/N)
FM: 0.4 uV (10 dB S+N/N)
|
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | 2-pin DIN |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 3.5 W |
| Modulation system: | |
| Max FM deviation (Factory set): | ±1.5 KHz |
| Spurious emissions: | Less than 2 nW |
| Microphone impedance / connector: | ? ohm / ?-pin DIN |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 198x-198x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | New price 1983 in Sweden: SEK 1295:- |
| Related documents: | |
| Market(s) / Approval(s): |
Sweden
Televerket: RI 3037/81
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
