Midland 13-881B

A picture of Midland 13-881B

SPECIFICATIONS

GENERAL
Type:Citizen band transceiver
Frequency range:26.965-27.255 MHz
Channels / tuning steps:23
Mode:AM
Frequency control:XTAL-matrix
Frequency stability:±?%
Clarifier or Delta tune:No
Power supply:12-15 VDC (Fixed power cord)
Current drain / power consumption:RX: ? mA
TX: ? A
Antenna impedance / connector:50 ohm / SO-239
Dimensions (W*H*D):197*57*248 mm (7.75*2.25*9.75")
Weight:2 Kg (4.5 lb)
Other features:PA. ANL. Dual watch.




RECEIVER SECTION
Receiver system: Double conversion superheterodyne
1st IF: 10.635 MHz
2nd IF: 455 KHz
Sensitivity:0.5 uV (6 dB S+N/N)
Selectivity:10 KHz (-6 dB)
Image rejection:
AF output power / speaker:? W at ?% distortion / 8 ohm
External speaker connector:3.5 mm, 8 ohm




TRANSMITTER SECTION
RF output power:4 W
Modulation system:
Max FM deviation (Factory set):No FM
Spurious emissions:Better than -? dB
Microphone impedance / connector:2 Kohm / 4-pin (Metal locking ring connector)
Microphone input level:? mV




MISCELLANEOUS
Manufactured:Japan, 1974-197x (Discontinued)
Main PCB:
Sub PCBs:
Additional info:
Related documents:User manual (2.3 MB)
Sams Photofact #:CB-74 (October 1975)
Modifications and fixes:
Reviews:
Options / Accessories:
- -
A rear picture of Midland 13-881B
