| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 23 |
| Mode: | AM / SSB |
| Frequency control: | XTAL-matrix |
| Frequency stability: | ±0.005% |
| Clarifier or Delta tune: | ±600 Hz |
| Power supply: | Mains: 110 VAC
or 12 VDC |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | ? mm (13*5*9.62") |
| Weight: | 7.71 Kg (17 lb) |
| Other features: | PA. NB. Alarm clock. SWR-meter. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 7.8 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM: 0.5 uV (6 dB S/N)
SSB: 0.25 uV (6 dB S/N)
|
| Selectivity: |
AM: 6 KHz (-6 dB)
SSB: 2.4 KHz (-6 dB)
|
| Image rejection: | |
| AF output power / speaker: | 3 W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
AM: ~3.5 W (5 W input)
SSB: ~11 W (15 W PEP input)
|
| Modulation system: |
AM: High level class B
SSB: Balanced
|
| FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 197x-197x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: | User manual (3.4 MB) |
| Sams Photofact #: | CB-42 (October 1972) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
